Transformer roller - 100mm Transformer roller with cast iron wheel - 800kg Load capacity | TC100AB-100040-01
- Part No.: TC100AB-100040-01
- Wheel Dia.: 100mm / 4inch
- Tread Width: 40mm / 1.58inch
- Wheel Type: Cast iron wheel
- Caster Type: Fixed transformer roller
- Fitting Type: Threaded stem
- Load Cap.: 800kg / 1765lbs
- APP: Transformer roller caster
Technical Data
Features
?100mm Trnasformer roller | TC100AB-100040-01
AgoodTec Transformer Rollers are for over twenty years leader in the production of Transformers Wheels Casters and supports for electrical transformers in oil or resin, its full range includes wheels for the distribution both in cast iron, the innovative Nylon-fiberglass and machined steel. The measures are from diameter 70 to diameter 410mm, and the load capacities are from 800kg to 70tons. It exports in 30 countries all over the world.
Featured ?100mm Trnasformer roller | TC100AB-100040-01
Cast iron wheel ?100 transformer caster with one M16×50 screw bolt and two nuts fixed bracket
Transformer roller bracket: Made of 6mm thickness pressed steel, RAL7033 painted.
Transformer wheel: ?100×40mm cast iron wheel, RAL7033 painted.
Certified maximum load capacity 800kg
Drawing
Accessories & Versions
Download
